Product Overview
Product Overview
Technical specifications for 1386-M4 Manufacturer Allen Bradley Product Type 4-Axis DC Servo Unit Product Line 1386 Servo Drives Part Number 1386-M4 Weight 13.06 lbs (5.93 kg) Control Voltage 105–125 V AC, 50/60 Hz, single-phase Input Voltage Range 35 V / 78 V AC Input Phase Operates on 1- or 3-phase input DC Bus Output 50 V / 106 V DC nominal Continuous Current (1-Ph) 27 A Continuous Current (3-Ph) 50 A Peak Current (1 s) 50 A (1-ph) / 100 A (3-ph) DC Overvoltage Clamp Activates near 120 V DC Overvoltage Trip Cuts off around 130 V DC Regeneration Capacity 140 W energy return Control Supply Load Approx. 0.5 A draw Auxiliary Supply Output ±15 V DC, 1 A max Operating Temperature 0 – 50 °C Request a Repair Description The 1386-M4 from Allen Bradley is a sophisticated 4-axis DC servo unit designed for precision control in automation tasks. With a control voltage range of 105 to 125 vol
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
