Technical specifications for 1746sc-INI4I Manufacturer Allen Bradley Product Type Isolated Analog Input Module Product Line SLC 500 Part Number 1746sc-INI4I Weight 0.44 lbs (0.20 kg) Channel Filtering Options Selectable for noise rejection or fast update Accuracy (Voltage Inputs) ±0.1% of full scale Accuracy (Current Inputs) ±0.1% of full scale Channel Update Rate 10 ms per channel Channel-to-Channel Isolation 1500 VDC Input Impedance (Voltage) 1 MΩ Input Impedance (Current) 250 Ω Resolution (Voltage Inputs) 16 bits Resolution (Current Inputs) 16 bits Voltage Input Ranges (INI4VI Variant) 0–5 V, 1–5 V, 0–10 V, ±10 V Current Input 0–20 mA, 4–20 mA Input Type Differential Current Inputs Number of Input Channels 4 Isolated Current Inputs View as PDF Request a Repair Description At the core of the 1746sc-INI4I is the function of isolating analog inputs for safe and accurate measurements. This module excels in managing noise and offers flexible filtering options to accommodat
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
