Product Overview
Product Overview
Technical specifications for 1746sc-NI8U Manufacturer Allen Bradley Product Type Universal Analog Input Module Product Line SLC 500 Part Number 1746sc-NI8U Weight 0.50 lbs (0.23 kg) Series SLC Module Type Universal Analog input module No. of output Six (6) individually isolated channels Channels 8 Compatible thermocouple sensors J, K, T, B, E, R, S, N, and C Input Types 31 Compatible RTD sensors PT385/3916, Ni618/672, Cu426 Input Current 0-20 mA Compatible resistance signals 0-3000 ohms Input Voltage 0-5 V Compatible current input signals 0-20 mA; 4-20 mA Input Overcurrent Protection 28 mA cont. Compatible voltage signals ±50 mV, ±100 mV, ±0.5 V ±2.0 V 0-5 V, 1-5 V, 0-10 V, and ±10 V Thermal Dissipation 3 W max. Input filters 10 Hz; 50 Hz; 60 Hz; 250 Hz UPC 850637004236 No, of channels 8 V, C, or TC, or 2 RTD/Res (2 groups of 4 Ch) Recommended Cable For TC inputs shielded, twisted-pair TC extension wire; Recommended cable For RTD, mV, V, or mA inputs Belden 8761 or equivalent; Rec
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
