Product Overview
Product Overview
Technical specifications for 2711P-K4M3DX Manufacturer Allen Bradley Category Panelviews Product Line Panelview Plus 400 Part Number 2711P-K4M3DX Weight 1.00 lbs (0.45 kg) Display Size 3.8 inches Product Family PanelView Plus Graphic Terminals Display Type Monochrome Passive Matrix, Film Compensated Super-Twist Nematic (FSTN) Display Area 78 x 59 mm (3.07 x 2.32 in) Resolution 320 x 240, 16-levels gray Backlight LED Keypad 8 function keys (F1…F8), Numeric input, navigation System Memory 5MB (Series A); 10 MB (Series B or later) Communication ports One (1) Ethernet; One (1) RS-232, One (1) USB External storage Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port Input Voltage range 18 to 32 VDC; 24VDc nominal Power Consumption 25 W max (1.0 A at 24V DC Temperature, operating 0…55 °C (32…131 °F) Heat dissipation 85 BTU/hr Shock, operating 15 g at 11 ms Display Color Gr
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
