Product Overview
Product Overview
Technical specifications for 2711P-K4M3DX Manufacturer Allen Bradley Category Panelviews Product Line Panelview Plus 400 Part Number 2711P-K4M3DX Weight 1.00 lbs (0.45 kg) Display Size 3.8 inches Product Family PanelView Plus Graphic Terminals Display Type Monochrome Passive Matrix, Film Compensated Super-Twist Nematic (FSTN) Display Area 78 x 59 mm (3.07 x 2.32 in) Resolution 320 x 240, 16-levels gray Backlight LED Keypad 8 function keys (F1…F8), Numeric input, navigation System Memory 5MB (Series A); 10 MB (Series B or later) Communication ports One (1) Ethernet; One (1) RS-232, One (1) USB External storage Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port Input Voltage range 18 to 32 VDC; 24VDc nominal Power Consumption 25 W max (1.0 A at 24V DC Temperature, operating 0…55 °C (32…131 °F) Heat dissipation 85 BTU/hr Shock, operating 15 g at 11 ms Display Color Gr
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
