Product Overview
Product Overview
Technical specifications for 509-DOD Manufacturer Allen Bradley Product Type DOL motor starter Product Line Bulletin 509 Part Number 509-DOD Weight 14.00 lbs (6.35 kg) UPC 781180218545 Control Voltage at 50 Hz 110 V AC Control Voltage at 60 Hz 120 V AC Continuous Current 90 A Service Limit Current 104 A Inrush Peak Current 947 A Maximum Motor Power 7.5 hp Transformer Rating 8.1 kVA Capacitor Load 67 kVAR Main Terminals Screw Mechanical Life 5 million operations Maximum Temperature 65 degrees Celsius Altitude Limit 10,000 ft Request a Repair Description The Allen Bradley 509-DOD serves as a direct-on-line (DOL) motor starter optimized for various industrial applications. This starter is capable of operating at control voltages of 110 V AC at 50 Hz or 120 V AC at 60 Hz, making it versatile across different operational environments. With a continuous current rating of 90 A, it can handle substantial loads without compromise. In scenarios where high-demand starts occur, the device can with
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
