Product Overview
Product Overview
Technical specifications for 512-BCCD-24R Manufacturer Allen Bradley Product Type Fused DOL starter Product Line 512 Series Part Number 512-BCCD-24R Weight 12.00 lbs (5.44 kg) UPC 10662072206260 Enclosure NEMA 4/4X SS Control Voltage 120 V AC Operating Voltage 575 V AC max Rated Current 27 A Max Service Current 32 A Fuse Type 30 A Class R Overload Type Eutectic thermal Short-Circuit Rating 100 kA RMS Inrush Current 288 A peak Motor Rating 10 HP Power Terminals Screw clamp Endurance 10 M ops Auxiliary Contacts 2 NO + 1 NC Request a Repair Description The model 512-BCCD-24R from Allen Bradley is a fused direct-on-line (DOL) starter engineered for efficient motor operation. Designed to accommodate an operating voltage of up to 575 V AC, this unit maintains a control voltage of 120 V AC for user convenience. Constructed within a NEMA 4/4X stainless steel enclosure, this starter is built to w
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
