Product Overview
Product Overview
Technical specifications for 825-PD Manufacturer Allen Bradley Product Type Modular Protection System Product Line 825 Smart Motor Managers Part Number 825-PD UPC 781180030994 Weight 3.69 lbs (1.67 kg) Voltage 24-48VDC Operating Range 0.80-1.1 Us Communication DeviceNet Rated Frequency (V ac) 50/60Hz +/- 5Hz Output Relay Rated Insulation Voltage 300V ac Output Relay Rated Operating Voltage 240V ac Input Operating Range 0.80-1.1 Ue Input On-state Voltage 15V Input Off-state Voltage 5V Input On-state Current 2mA Input Off-state Current 0.5mA Protection features • Thermal Overload (thermal model) • PTC (positive temperature coefficient) Overtemperature • Undercurrent (Load Loss) • Current Imbalance and Phase Loss • Overcurrent (Load Jam) • Short Circuit • Ground Fault (Residual) • Ground Fault (Zero Sequence) • Motor Starting/Running – Protection Inhibit During Start – Start Motor Timer – Notching or Jogging Device – TCU (Thermal Capacity Utilization) Start Inhib
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
