Product Overview
Product Overview
Technical specifications for 825-PD Manufacturer Allen Bradley Product Type Modular Protection System Product Line 825 Smart Motor Managers Part Number 825-PD UPC 781180030994 Weight 3.69 lbs (1.67 kg) Voltage 24-48VDC Operating Range 0.80-1.1 Us Communication DeviceNet Rated Frequency (V ac) 50/60Hz +/- 5Hz Output Relay Rated Insulation Voltage 300V ac Output Relay Rated Operating Voltage 240V ac Input Operating Range 0.80-1.1 Ue Input On-state Voltage 15V Input Off-state Voltage 5V Input On-state Current 2mA Input Off-state Current 0.5mA Protection features • Thermal Overload (thermal model) • PTC (positive temperature coefficient) Overtemperature • Undercurrent (Load Loss) • Current Imbalance and Phase Loss • Overcurrent (Load Jam) • Short Circuit • Ground Fault (Residual) • Ground Fault (Zero Sequence) • Motor Starting/Running – Protection Inhibit During Start – Start Motor Timer – Notching or Jogging Device – TCU (Thermal Capacity Utilization) Start Inhib
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
