Product Overview
Product Overview
Technical specifications for 3RT1056-6AB36 Manufacturer Siemens Product Type Contactor Product Line SIRIUS Part Number 3RT1056-6AB36 UPC 754554771731 Weight 3.00 lbs (1.36 kg) Series Contactors Rated Operational Current (AC-3) 185 A Rated Operational Power (AC-3) 90 kW at 400 V Rated Control Supply Voltage 23-26 V (AC/DC) Number of Poles 3-pole configuration Auxiliary Contacts 2 Normally Open (NO) + 2 Normally Closed (NC) Size S6 Connection Type Busbar connections for the main circuit Control and Auxiliary Circuit Connection Screw Terminals Surge Voltage Resistance 8 kV for the main circuit and 6 kV for the auxiliary circuit Shock Resistance 8.5g/5 ms and 4.2g/10 ms for rectangular impulse Mechanical Service Life 10 million switching cycles Maximum Installation Altitude 2000 meters above sea level Rated Voltage Up to 1000 V for the main circuit Ambient Temperature -25°C to +60°C during operation Request a Repair Description The Siemens 3RT1056-6AB36 contactor efficiently manages high
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
