Product Overview
Product Overview
Technical specifications for 3RT1466-6AB36 Manufacturer Siemens Product Type Vacuum Contactor Product Line SIRIUS Part Number 3RT1466-6AB36 UPC 754554773414 Weight 6.63 lbs (3.01 kg) Ambient Operating Temperature -25 to 60°C (in a non-condensing environment) Storage Temperature -55 to 80°C (in a non-condensing environment) Number of Poles 3 poles Contact Voltage Rating 690 Volts Contact Current Rating 400 Amperes Coil Voltage 23 to 26 Volts AC/DC Contactor Size S10 Maximum Operating Voltage 1,000 Volts AC Electrical Connection Type Connection bar and screw-type terminals Protection Rating IP20 for the front cover and IP00 for the terminal and the front with no cover Installation Altitude Up to 6,561.68 feet (2,000 meters) above sea level Control Circuit Design Surge suppressor with varistor Surge Voltage Resistance 6 kilovolts for the auxiliary circuit and 8 kilovolts for the main circuit Mounting Method Screw mount Request a Repair Description The 3RT1466-6AB36 vacuum contactor from
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
