Product Overview
Product Overview
Technical specifications for 6AV6542-0CC10-0AX0 Manufacturer Siemens Product Type Operator Panel (HMI) Product Line SIMATIC Part Number 6AV6542-0CC10-0AX0 UPC 662643209822 Weight 9.94 lbs (4.51 kg) Display Size 10.4-inch Display Type STN Color, 256 colors Supply Voltage 24V DC Processor RISC 32-bit MTBF (Backlight) 60,000 hours Resolution 640 x 480 pixels (VGA) Protection Rating IP65 (Front) / IP20 (Rear) Certifications CE, UL, cULus, FM Div 2, ATEX Zone 2/22, etc. Input Method Touchscreen + Membrane Keyboard Mounting Style Vertical Panel Mount Configuring Memory 2 MB Flash Communication Ports 2x RS232, 1x RS422, 1x RS485, USB Request a Repair Description The 6AV6542-0CC10-0AX0 from Siemens is an operator panel belonging to the SIMATIC series. Equipped with a 10.4-inch display, it utilizes STN color technology, capable of displaying 256 colors. The panel boasts a resolution of 640 x 480 pixels, providing clear visuals for operators. This device operates on a 24V DC supply voltage and i
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
