Technical specifications for 6FC5203-0AF05-0AB0 Manufacturer Siemens Product Type Operator Panel Front Interface Product Line SINUMERIK Part Number 6FC5203-0AF05-0AB0 Weight 18.69 lbs (8.48 kg) Display Diagonal 15-inch TFT Color XGA Screen Native Resolution 1024 x 768 Pixels Environmental Compliance EN60721-3-3 (Condensation/Icing Excluded) Supply Voltage DC 5 V (Sourced via PCU/TCU) Operating Temperature Range 0°C to 45°C (Front), 0°C to 55°C (Rear) Storage/Transport Temperature Range -20°C to 55°C Relative Humidity Tolerance 5% to 95% (Non-Condensing) Peak/Nominal Power Consumption 25 W (Max), 15 W (Typical) Physical Dimensions (W x H x D) 483.0 mm x 355.0 mm x 53.0 mm Front Panel Protection Rating IP65 Mounting Cutout Requirements 450.0 mm (Width) x 335.0 mm (Height) User Input Interface Membrane Keys with Integrated Pointing Device Request a Repair Description The 6FC5203-0AF05-0AB0 model from Siemens is a front interface for operator panels in the SINUMERIK series. The displ
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
