Product Overview
Product Overview
Technical specifications for 6FC5203-0AF05-0AB0 Manufacturer Siemens Product Type Operator Panel Front Interface Product Line SINUMERIK Part Number 6FC5203-0AF05-0AB0 Weight 18.69 lbs (8.48 kg) Display Diagonal 15-inch TFT Color XGA Screen Native Resolution 1024 x 768 Pixels Environmental Compliance EN60721-3-3 (Condensation/Icing Excluded) Supply Voltage DC 5 V (Sourced via PCU/TCU) Operating Temperature Range 0°C to 45°C (Front), 0°C to 55°C (Rear) Storage/Transport Temperature Range -20°C to 55°C Relative Humidity Tolerance 5% to 95% (Non-Condensing) Peak/Nominal Power Consumption 25 W (Max), 15 W (Typical) Physical Dimensions (W x H x D) 483.0 mm x 355.0 mm x 53.0 mm Front Panel Protection Rating IP65 Mounting Cutout Requirements 450.0 mm (Width) x 335.0 mm (Height) User Input Interface Membrane Keys with Integrated Pointing Device Request a Repair Description The 6FC5203-0AF05-0AB0 model from Siemens is a front interface for operator panels in the SINUMERIK series. The displ
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
