Product Overview
Product Overview
Technical specifications for 6SL3201-0BE21-8AA0 Manufacturer Siemens Product Line SINAMICS Part Number 6SL3201-0BE21-8AA0 UPC 887621217785 Weight 2.75 lbs (1.25 kg) Description Braking Resistor Resistance 75 Ω Rated Power 0.375 kW Maximum Power 7.5 kW (12 s, 5% duty cycle) DC Link Voltage Range 330 to 840 V DC Input Current (max) 2.5 A Temperature Switch Type Normally closed contact Temperature Switch Voltage (max) 250 V AC Temperature Switch Current (max) 2.5 A Enclosure Type IP20 Operating Temperature Range -25 to 40 °C Request a Repair Description The Siemens 6SL3201-0BE21-8AA0 is a braking resistor, primarily intended to manage excess energy in electrical drive systems. It features a resistance value of 75 Ω and has a constant rating power of 0.375 kW. For brief intervals, it can withstand maximum power loads reaching up to 7.5 kW with a 5% duty cycle. The component operates within a DC link voltage range of 330 to 840 V DC. Max input current can be accommodated at 2.5 A, ensuri
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
